QSeven

The Qseven® standard has proven itself to be the most compact and cost efficient Computer on Module on the embedded market. Key benefits include low power consumption, interchangeability among architectures and reduced time to market. The GSR Qseven range delivers high performance on a small footprint, ideal for space limited and mobile applications.

Enquire About This Product

  • This field is for validation purposes and should be left unchanged.
Product NameCPUGraphicsTemperatureMemoryHighlights
Q7-928NXP i.MX6 Family, based on ARM® CORTEX-A9 processorsDedicated 2D Hardware accelerator
Dedicated 3D Hardware accelerator, supports OpenGL® ES 2.0 3D Dedicated Vector Graphics accelerator supports OpenVG™
0°C - +60°C (Commercial version)
-40°C - +85°C (Industrial version)
Up to 4GB DDR3L on-board (up to 2GB with i.MX6S)A scalable multi-core ARM® Cortex™-A9 architecture in Qseven® standard modular form factor
Combines high-graphics performance with power-efficient processing capabilities
Enhanced 2D and 3D graphics with i.MX6DP
OpenGL (FULL) and OpenGL ES 2.0 3D Graphics supporting up to 3 independent displays (only up to 2 displays with i.MX6DL and i.MX6S)
Flexible solution: from multi-display platforms to mobile fanless applications
Q7-974Intel® Atom E3845, Quad Core @1.91GHz, 2MB Cache, 10W TDP Intel®Integrated IntelR HD Graphics 4000 series controller
Dual independent display support
HW decoding of H.264, MPEG2, MVC, VC1, VP8, MJPEG formats
HW encoding of H.264, MPEG2 and MVC formats
0°C - +60°C (Commercial version)
-40°C - +85°C (Industrial version)
Soldered on-board DDR3L memory

SATA Flash Drive soldered on-board
Security enhancement and content protection
Available in Industrial temperature range
Integrated 64-bit memory controller
Low power solution
Q7-A36Intel® Atom™ E3845, Quad Core @1.91GHz, 2MB Cache, 10W TDPIntegrated Intel® HD Graphics 4000 series controller (not for E3805)
Dual independent display support
HW decoding of H.264, MPEG2, MVC, VC1, VP8, MJPEG formats
HW encoding of H.264, MPEG2 and MVC formats
0°C - +60°C (Commercial version)
-40°C - +85°C (Industrial version)
Soldered on-board DDR3L memoryeMMC drive on-board
Available in Industrial temperature range
Low power solution
Camera Interface
Integrated 64-bit memory controller

Q7-B03Intel® Atom™ x5-E3930 Dual Core @1.3 GHz (Burst 1.8GHz), 2MB
L2 Cache, 5.5W TDP
Integrated Gen9-LP Graphics controller, with 18 Execution Units
4K HW decoding and encoding of HEVC(H.265), H.264, VP8, SVC,
MVC
0°C - +60°C (Commercial version)
-40°C - +85°C (Industrial version)
Dual Channel Soldered Down DDR3L-1866 memory, up to 8GBCompliant to the most recent Qseven® rel. 2.1 specs
4K HW decoding and encoding of HEVC(H.265), H.264,
VP8, SVC, MVC
Extreme graphics for low power embedded applications
Industrial grade and connectivity capable
Support for the most popular operating systems
Q7-B25NXP i.MX 8M Family based on ARM Cortex®-A53 cores + general purpose Cortex®-M4 processorIntegrated Graphics Processing Unit, supports 2 independent displays
Embedded VPU, supports HW decoding of HEVC (H.265) H.264, H.263, MPEG-4, MPEG-2, AVC, VC-1, RV, DivX, VP6, VP8, VP9, JPEG
Supports OpenGL ES 3.1, Open CL 1.2. OpenGL 2.X, Vulkan,
0°C - +60°C (Commercial version)
-40°C - +85°C (Industrial version)
Soldered Down LPDDR4-3200 memory, 32-bit interface, up to 4GBA scalable solution for applications like domotics or
vending, requiring advanced security, connectivity and
multimedia
Multicore processing: Dual or Quad ARM Cortex®-A53
cores + general purpose Cortex®-M4 processor
Integrated Cortex®-M4 processor for realtime
applications
4Kp60 HEVC decoding with HDR
Q7-C26NXP i.MX8 Family:Integrated Graphics Processing Unit, supports 2 independent
displays.
Embedded VPU, supports HW decoding of HEVC/H.265,
AVC/H.264, MPEG-2, VC-1, RV9, VP8, H.263 and MPEG4 part,
HW encoding of AVC/H.264
Supports OpenGL ES 3.1, Open CL 1.2, OpenGL 3.x, DirectX 11
0°C - +60°C (Commercial version)
-40°C - +85°C (Industrial version)
Soldered Down LPDDR4-3200 memory, 64-bit interfaceAdvanced multimedia
Rich m2m interface to control onboard
subsystems
Wide connectivity
