Passive Displays

GSR Technology is able to provide a wide range of industry standard, semi-custom or fully customised passive display products, all of our products are very competitive with today’s robust market conditions.

We offer standard ranges of character modules from 1 x 8 at the smallest end of the range to large size graphics panels at 640 x 480 pixels.

As well as wide range of possibilities in the 7 segment – glass only product – a wide range of technologies is offered from standard TN through to fully customised high end automotive range ISTN product along with a variety of packages such as COG and COB. Extremely wide temperature fluids are available to suit industrial and extreme environmental conditions throughout the product range.

LED backlighting is also available in standard, bi colour and tri colour customised packages to suit customer requirements as well as a wide variety of connection possibilities such as bonded pins, FPC and elastomeric technologies.

Enquire About This Product

  • This field is for validation purposes and should be left unchanged.
Display Format (dots)Viewing area (mm)Module Size (mm)Model No.Backlight TypeInterface
8 x 235.50 x 14.5058.00 x 32.00GSR4082AL / M / -4-bit / 8-bit
10 x 164.50 x 15.4080.00 x 36.00GSR4101A- / M / -4-bit / 8-bit
16 x 164.00 x 13.8080.00 x 36.00GSR4161HL / M / -4-bit / 8-bit
16 x 199.00 x 13.00122.00 x 33.00GSR4161B- / M / -4-bit / 8-bit
16 x 199.00 x 14.00102.40 x 24.40GSR9161A- / - / -4-bit / 8-bit
16 x 243.90 x 10.0048.20 x 21.00GSR9162EL / - / -4-bit
16 x 261.00 x 15.8070.50 x 26.00GSR9162HL / M / -4-bit
16 x 261.00 x 15.8080.00 x 36.00GSR4162DL / M / -4-bit / 8-bit
16 x 261.00 x 15.8080.00 x 36.00GSR4162FL / M / -4-bit / 8-bit
16 x 261.00 x 15.8084.00 x 44.00GSR4162HL / M / -4-bit / 8-bit
16 x 262.00 x 16.0085.00 x 30.00GSR4162CL / M / -4-bit / 8-bit
16 x 264.00 x 13.8080.00 x 36.00GSR4162BL / M / E4-bit / 8-bit
16 x 279.00 x 16.1083.00 x 27.40GSR9162DL / - / -4-bit
16 x 299.00 x 24.00102.60 x 36.00GSR9162FL / - / -4-bit / 8-bit
16 x 299.00 x 24.00122.00 x 44.00GSR4162EL / M / -4-bit / 8-bit
16 x 462.00 x 25.0087.00 x 60.00GSR4164BL / M / -4-bit / 8-bit
20 x 283.00 x 18.60116.00 x 37.00GSR4202AL / M / -4-bit / 8-bit
20 x 283.00 x 18.60116.00 x 37.00GSR4202CL / - / -4-bit / 8-bit
20 x 2123.00 x 23.00146.00 x 43.00GSR4202BL / M / -4-bit / 8-bit
20 x 476.00 x 25.0080.00 x 35.80GSR9204AL / - / -4-bit / 8-bit / I2C Serial
20 x 476.00 x 25.0098.00 x 60.00GSR4204BL / M / -4-bit / 8-bit
20 x 4123.00 x 42.50146.00 x 62.50GSR4204CL / M / -4-bit / 8-bit
24 x 293.50 x 15.80118.00 x 36.00GSR4242A- / - / -4-bit / 8-bit
40 x 2154.00 x 15.80182.00 x 33.50GSR4402B- / M / -4-bit / 8-bit
40 x 2154.00 x 16.50182.00 x 34.50GSR4402C- / M / -4-bit / 8-bit
40 x 4154.40 x 27.50196.00 x 56.00GSR4404A- / M / -4-bit / 8-bit
40 x 4244.00 x 68.00280.00 x 88.00GSR4404DL / - / -4-bit / 8-bit
10 Digits + Icons39.00 x 9.2042.00 x 19.50GSR9003A- / - / -I2C
10 Alphanumerics + Icons39.00 x 9.2042.00 x 19.50GSR9004A- / - / -I2C
84 x 2447.70 x 16.7055.00 x 30.00GSR8424A- / - / - / -4-bit
98 x 6434.00 x 22.0037.00 x 33.00GSR9018AL / - / - / -Serial
100 x 6528.00 x 26.7032.50 x 37.00GSR9021AL / - / - / -Serial
120 x 2460.50 x 17.7084.00 x 44.00GSR12024AL / - / - / -4-bit
120 x 3262.50 x 23.5084.00 x 44.00GSR12032AL / M / E / -8-bit
120 x 3262.50 x 23.5084.00 x 44.00GSR12032CL / M / E / -4-bit / 8-bit
128 x 1670.00 x 12.00106.00 x 34.00GSR12816A- / M / - / -8-bit
128 x 3276.00 x 22.2084.30 x 36.30GSR12832AL / - / - / -I2C
128 x 6430.40 x 20.9034.40 x 31.60GSR9020BL / - / - / -8-bit
128 x 6430.40 x 20.9034.40 x 32.60GSR12864CL / - / - / -Serial
128 x 6437.04 x 20.2444.30 x 30.14GSR12864AL / - / - / -Parallel / Serial
128 x 6452.00 x 26.5061.00 x 38.50GSR9007DL / - / - / -Serial
128 x 6459.00 x 30.3564.00 x 47.35GSR9007EL / - / - / -8-bit
128 x 6462.00 x 44.0078.00 x 70.00GSR12864BL / M / E / -8-bit
128 x 6462.00 x 44.0078.00 x 70.00GSR12864CL / M / - / -8-bit
128 x 6470.60 x 38.6078.40 x 53.00GSR12864D- / - / - / -Serial
128 x 6470.60 x 38.6078.40 x 53.00GSR12864BL / - / - / -Parallel / Serial
128 x 12869.00 x 69.0075.40 x 83.40GSR128128AL / - / - / -8-bit / Serial / I2C
132 x 12850.00 x 42.0055.00 x 56.00GSR9132AL / - / - / -Serial
144 x 1292.00 x 11.80100.00 x 30.00GSR14412A- / - / - / -4-bit
160 x 16049.00 x 46.0053.00 x 57.00GSR160160BL / - / - / -Parallel / Serial
160 x 16062.00 x 62.0089.20 x 85.00GSR160160AL / - / - / -4-bit
160 x 16069.00 x 69.0075.40 x 83.40GSR160160DL / - / - / -Parallel / Serial / I2C
240 x 64102.40 x 30.22108.00 x 43.22GSR24064BL / - / - / -Parallel / Serial
240 x 64132.00 x 39.00180.00 x 65.00GSR24064BL / M / - / -8-bit
240 x 12861.50 x 34.5073.00 x 45.80GSR240128AL / - / - / -Parallel / 3line or 4line SPI
240 x 12879.00 x 43.50100.30 x 57.80GSR240128CL / - / - / -Parallel / 3line or 4line SPI
240 x 128114.00 x 64.00144.00 x 104.00GSR240128A- / M / - / C8-bit
240 x 16061.60 x 42.5077.00 x 54.20GSR240160BL / - / - / -4-bit
240 x 16061.60 x 42.5077.00 x 54.20GSR240160CL / - / - / -4-bit / 8-bit
240 x 16065.90 x 46.0073.00 x 60.30GSR240160DL / - / - / -Parallel / Serial
240 x 16086.00 x 62.8096.40 x 78.20GSR240160CL / - / - / -Parallel / Serial
320 x 24081.38 x 62.18100.00 x 77.70GSR320240DL / - / - / -4-bit
320 x 24081.38 x 62.1897.70 x 75.00GSR320240FL / - / - / -4-bit / 8-bit
320 x 24086.00 x 62.8096.40 x 78.20GSR320240BL / - / - / -4 Line Serial
320 x 240122.00 x 92.00161.00 x 112.00GSR320240AL / - / - / -4-bit
320 x 240122.00 x 92.00161.00 x 112.00GSR320240EL / - / - / -8-bit
640 x 200232.16 x 106.17256.29 x 128.02GSR640200AL / - / - / -4-bit
640 x 480198.00 x 150.00256.30 x 174.00GSR640480A- / - / - / C4-bit

Backlight Type Key: N = No backlight, L = Side-lit Backlight, M = Array LED Backlight, E = EL Backlight, C = CCFL
